Description

The Wrekin B125 Hinged & Dished Gully Grating is a robust and reliable choice for effective drainage, ideal for urban and industrial environments. Designed for optimal water flow and long-lasting performance, this gully grating features advanced design elements that simplify maintenance and enhance security, making it a valuable asset for any drainage system.

Built to meet BS EN124:2015 standards, this grating includes a captive hinge that aids in maintenance while serving as a theft deterrent. It also offers versatile options such as enhanced anti-slip coating and a screw-locking mechanism to meet specific needs.

Features & Benefits:

  • Captive hinge for easy maintenance and theft deterrence.
  • Optional anti-slip coating for added safety.
  • Available screw-locking mechanism for enhanced security.
  • Complies with BS EN124:2015 standards.
  • Weight Class: B125
  • Weight Group: 2
  • Waterway Area: 375 cm²
  • Seating Depth: 30mm
  • Depth of Insertion: 30mm
  • Dished Depth: 15mm
  • Dimensions: 302 x 302 x 75mm
    Specification
    Weight 14.00 kg
    Manufacturer Code DGH0B3/3030
    Brand Wrekin
    Material Metal
    Material Type Ductile Iron
    Range Tristar
    Shape Rectangular
    Type Gully grate
    Length 302mm
    Thickness 75mm
    Width 302mm
